Digital Micro Vickers Hardness Tester Hv1 Hardnes | RFQ Sourcing Details
Testing And Measurement Equipment · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Product specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Testing And Measurement Equipment. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
Digital Micro Vickers Hardness Tester HV1 Hardness ASTM e92 and ASTM e384 Main Features: 1. One-time casting aluminum machine body with car painting technology, structure more stable and appearance more decent. 2. With LCD screen display, directly display hardness value, dwell time, conversion hardness value, etc. 3.
Menu structure interface, easy operation. 4. With HV / HK test function (if need HK test function, optional purchase Knoop diamond indenter and standard hardness blocks). 5. Digital eyepiece with encoder, only click the button on encoder, the D1, D2 value will input machine automatically.
No need manually input the value of diagonal length. Easy operation, greatly improve working efficiency, and test result more accurate. 6. With built-in printer, test result can be printed out directly. 7.
With RS232 communication port, purchase our data transfer software via RS232 port can save test data to computer and by software can control machine (for Automatic turret machine) 8. Double optical path design. Both eyepiece and CCD camera path can work at same time. No need switch optical path.
Camera can be install inside machine (camera for optional purchase). Main purpose and application: 1. Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure. 2. Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating. 3.
Glass, chip and ceramic material.
Specification: Model eKIck-1DM eKIck-1DA Turret Manual turret Automatic turret Test force 10gf (0.098N) , 25gf (0.245N) , 50gf (0.49N) , 100gf (0.98N) , 200gf (1.96N) , 300gf (2.94N) , 500gf(4.9N) , 1kgf (9.8N) Hardness scale HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1 Conversion Scale HRA , HRB , HRC , HRD , HRF , HV , HK , HBW , HR15N , HR30N , HR45N , HR15T , HR30T , HR45T Hardness range 8-4500HK Min measuring unit 0.01µm Data display LCD screen Data output built-in printer, RS-232 port Maximum height allowed for testing 90mm Throat depth 95mm X-Y Testing table Dimension: 100x 100mm Max mo vement: 25 x25mm Force loading type Automatic ( Loading, Dwell, Unloading) Magnification Eyepiece: 10X;Objective: 10X (observation use);40X (measuring use) Total: 100X ( observation );400X (Measuring) Duration time 1 ~ 99 s Power supply AC220V± 5% , 50-60.
Hz Machine size 405*290*480mm;Net weight: 40kg Package size 530x 350 x 820mm;Gross we
